2020 Mercury 9.9 HP 9.9ELHPT-CT-PK Outboard Motor
Mercury 9.9 HP outboard motors with Command Thrust provide the power, thrust and control that larger, heavier boats need. The 20% larger propeller enhances control, and the taller gear housing places the propeller deeper under the eddy for improved performance. Low 2.42:
1 and high-thrust propellers make the Mercury 9.9 103lb outboard motor an excellent choice for sailing and trolling applications. The oversized Command Thrust anti-vent plate prevents air from being drawn into the blades, further enhancing efficiency and performance. Mercury 9.9 HP outboard motor model:
The 9.9ELHPT-CT-PK features a 20-inch shaft and an electric starter, an electric tilt and Mercury multifunction tiller handle that allows one-handed operation to switch F-N-R speed, throttle and throttle voltage, direction and stop.
- Compact and Lightweight
- Designed for Heavy Applications
- CommandThrust Lower Unit (2.42:1 Gear Ratio)
- High Thrust Propeller
- Oversized Anti-Ventilation Plate
- Electric Start + 12V 76W 6A Alternator
- Thru-Cowl Backup Manual Start
- Digital CD Ignition with Spark Advance
- High Grade Marine Alloy Construction
- Stainless Steel Water Pump Housing
- Zinc Coated Water Passages
- Rated for Saltwater Use
- Sacrificial Zinc Anodes and Trim Tab
- Tiller Integrated F-N-R Gear Shifting
- Adjustable Steering Tension Control
- Twist-Grip Throttle with Tension Control
- Thermostat Controlled Water Cooling
- Heavy Duty Transom Mounting Bracket
- Power Operated Tilt (Range: -4° to 75°)
- Quiet Through-Propeller-Hub Exhaust
- 3.2 Gallon Fuel Tank and Fuel Line
- Start-In-Gear Protection
- Low Oil Pressure Warning Indicator
- ESG Over-Rev Protection
- Safety Lanyard Stop Switch
- Owner’s Manual
- Mercury Marine 3-Year Warranty
| MODEL | 9.9ELHPT-CT-PK |
|---|---|
| MODEL YEAR | 2020 |
| SKU | 9.9ELHPT-CT-PK-20 |
| WEIGHT | 111.0 lb |
| MANUFACTURER | Mercury |
| COUNTRY OF MANUFACTURE | Japan |
| HORSEPOWER | 9.9hp |
| SHAFT LENGTH | 20″ (Long) |
| STEERING | Tiller |
| STARTING | Electric |
| TRIM & TILT | Power Tilt |
| FUEL DELIVERY | Carburetor |
| FUEL TANK | External |
| CYLINDER(S) | 2 |
| DISPLACEMENT | 208 cc (12.8 cubic inches) |
| BORE AND STROKE | 55 x 44 mm (2.16 x 1.73 inches) |
| FULL THROTTLE RPM RANGE | 5000-6000 |
| IGNITION SYSTEM | Digital CD Ignition w/Electronic Spark Advance |
| INDUCTION SCAVENGING | SOHC |
| VALVES PER CYLINDER | 2 |
| FUEL TYPE | 87 Octane (up to 10% ethanol content) |
| FUEL TANK / FUEL LINE | 3.2 Gal. Fuel Tank + Quick Connect Fuel Line |
| OIL TYPE | SAE 10W-30 (Mercury 4-Stroke Outboard Oil) |
| OIL CAPACITY | 27 fl. Oz. (800 ml) |
| LUBRICATION | Trochoid Pump |
| ALTERNATOR | 12V 76W 6A (standard on electric start models) |
| COOLING SYSTEM | Water-Cooled, Thermostatically Controlled |
| SALTWATER RATED | Yes |
| GEAR RATIO | 2.42:1 CommandThrust Gearcase |
| GEAR SHIFT | Forward-Neutral-Reverse (shift in tiller handle) |
| PROPELLER | CommandThrust 4-Blade High Thrust Aluminum Propeller |
